Price upon request
Ordering Information | Motor | Flow Rate (Pumping Speed) | Ultimate pressure in mbar (Torr) | Additions | |
Voltage | Frequency | ||||
411011 | 90-260V | 50/60Hz | 0.35 cfm / 10l/min | 75 torr / 100 mbar | - |
411011-01 | 90-260V | 50/60Hz | 0.35 cfm / 10l/min | 75 torr / 100 mbar | filtration package (vacuum hose and hydrophrob filter) |
Ordering information | 411011 |
Number of heads / stages | 2/1' |
Max. pumping speed at 60 Hz in cfm (l/min) | 0.35 cfm / 10l/min |
Ultimate pressure in mbar (Torr) | 100 mbar (75 Torr) |
Wired for | 90 to 260V AC |
Intake connection | Hose nozzle DN 6 |
Exhaust connection | Hose nozzle DN 6 with removable exhaust silencer |
Sound level (dB) | < 45 |
Dimensions (W/D/H) in mm | 144/127/196 |
Operating temperature in °C | 10 - 60 °C |
Weight kg (lbs) | 2.3 (5.1) |
MP 055 Z - pumping speed 50/60 Hz 8/9.2 l/min ✓ motor power 68 W ✓ oil-free ✓ compact ✓ heads 2 / stages 2
MP 105 E - pumping speed 50/60 Hz 8/9.1 l/min ✓ motor power 68 W ✓ oil-free ✓ wired for 115/230V , 50/60Hz
